0.1" Pitch 30-Pin Right-Angle PCB Socket

Pan Pacific PBS-30R — 0.1" Pitch 30-Pin Right-Angle PCB Socket The Pan Pacific PBS-30R is a board-mount PCB socket that provides 30 contact positions on a 0.1" centerline in a right-angle orientation. It serves as a reliable interface for mating header assemblies where a low-profile, perpendicular connection is required at the PCB edge. The PBS-30R supports repeatable connections useful for signal routing, control interfaces, and harness terminations commonly found in OEM assemblies, field service repairs, and prototype builds. Because it uses the standard 0.1" pitch, the socket is compatible with widely used 0.1" headers and assembly tooling, helping reduce redesign and procurement complexity. The right-angle format improves cable routing and minimizes vertical space inside enclosures and racks. For maintenance and repair operations, stocking a common, easy-to-install socket like the PBS-30R simplifies replacement and reduces downtime. Confirm mating-part geometry and board footprint during layout and replacement to ensure fit and function. Tri-Tek Electronics supports customers in Phoenix, Mesa, Chandler, Tempe, Gilbert, Scottsdale, Glendale, and nationwide with parts availability and logistics solutions. Key Features: 30 contact positions (30-pin) 0.1" (2.54mm) centerline / pitch Right-angle orientation for low vertical profile PCB-mount socket for board-level interconnects Specifications: Manufacturer: Pan Pacific MPN: PBS-30R Typical applications include OEM product assemblies, field service and MRO repairs, AV and security system installs, control-panel connections, and bench-level prototyping. The PBS-30R is appropriate where a dependable, serviceable 30-pin board interface is required. Installation example: during an AV rack build, a technician installs the PBS-30R on a printed circuit board to accept a mating 30-pin harness at a right angle, allowing tidy cable routing behind the rack and simplifying later replacement without desoldering complex wiring. Tri-Tek Electronics is an authorized distributor for Pan Pacific products and offers full manufacturer warranty support plus nationwide availability and shipping from our Arizona location.
